The vibration generator is used to generate mechanical waves for demonstrating and studying oscillations and resonances in school education and training. The vibration generator consists of a speaker housed in a sturdy plastic case. Mounted on the speaker is a mounting pin with a 4mm jack for transmitting vibrations. On the back of the device, there is a mount for tripod rods (up to 8mm Ø) for demonstrating standing waves in a coil spring. The generator is equipped with overload protection. To generate the oscillations, a function generator with a power output is needed.
- Connection: via 4mm safety sockets
- Impedance: 8Ω
- Minimum operating current: 10mA
- Overload protection: 1A fuse
- Frequency range: 0 up to 20kHz
- Maximum amplitude: 5mm
- Dimensions: approx. 200 x 160 x 70 mm
- Weight: approx. 1.4kg
